Top used machines from the manufacturer
as good as new, modernized, overhauled or in used original condition
UBF - the universal bed milling machine for economical multi-sided machining of larger workpieces
Universal bed milling machine UBF 3000/16
Year of manufacture 8/2013, machine number F53270, well maintained, very good condition
- 2-axis universal head automatically infinitely adjustable, with hydraulic clamping
- Tool holder SK50 according to DIN 69871/872
- Longitudinal travel of the table (X-axis) 3000 mm
- Cross travel of the headstock (Y-axis) 1600 mm
- Vertical travel of the headstock (Z-axis) 1600 mm
- Table size 3200 x 1320 mm, with T-slots 22 mm, distance 140 mm
- Table load 7000 kg
- Spindle power 30 kW (100% ED), max. torque 1120 Nm
- Spindle speed 20 - 7000 rpm (in 2 ranges continuously variable), with oil cooling
- Axis speeds 5 m/min or 18 m/min rapid traverse, X-axis 27 m/min
- CNC control Heidenhain iTNC 530 with fast CC424 and electronic handwheel HR 410
- Coolant system with internal cooling up to 50 bar, adjustable via potentiometer. Air/water switching.
- Edge gap filter with 600 l clean water tank and rinsing gun
- Tool changer with 50 positions max. Ø 125/250 mm, max. 400 mm long
- 3D probe m&h with radio transmission, remote diagnosis, BA3 and BA4
- Work area paneling all around, also closed at the top, with 2 chip conveyors
- Connection data 400 V; 50 Hz; approx. 55 kVA
- with mounting elements (fixators), without assembly and commissioning
